Schertler Pickup for Acoustic Bass Guitar - DYN ABG Dynamic Sound Board Contact Microphone

acoustic bass guitar | cello | double bass | hammered dulcimer, mountain dulcimer, autoharp
guitar | classical and celtic harp | mandolin | percussion instruments, sitar | piano / grand piano | violin / viola

Acoustic Bass Guitar, DYN-ABG
List ~~$845.00~~ with a 2 year warranty - Call or email for best price


*Add a NEW* PRE-AIII pre-amp, combo list ~~$1384.00~~**

Need a quality microphone cable- in colors? Kordstar (formerly Kordex) cables

Order a spare canister of Putty

TRANSDUCER SPECIFICATIONS
MECHANICAL DECOUPLING ............... Butterworth 2nd order, Q=0.6 NOMINAL IMPEDANCE ......................................1500 ohms / 1000 Hz FREQUENCY RESPONSE ............................20 TO 18,000 Hz +/- 3 dB DYNAMIC RANGE ......................................... 139 dB, 145 dB typical EQUIVALENT OUTPUT NOISE .................. 16dB / OdB=0.002 dyn/cm SENSITIVITY............... ............................................. 2mV / m /sec^2 SENSITIVITY (ON INSTRUMENT) ....................................... ca -30 dB TEMPERATURE RANGE ............................................ -20 to 70 deg C CONTACTS ..................................................................all hard gold CONNECTION ............................... XLR, balanced (2m cable length) 0dB = 0dBm=0.775V WEIGHT.......... < 1 oz SIZE ............. 1 1/2 inches in diameter

TRANSDUCER SPECIFICATIONS

MECHANICAL DECOUPLING ............... Butterworth 2nd order, Q=0.6
NOMINAL IMPEDANCE ......................................1500 ohms / 1000 Hz
FREQUENCY RESPONSE ............................20 TO 18,000 Hz +/- 3 dB
DYNAMIC RANGE ......................................... 139 dB, 145 dB typical
EQUIVALENT OUTPUT NOISE .................. 16dB / OdB=0.002 dyn/cm
SENSITIVITY............... ............................................. 2mV / m /sec^2
SENSITIVITY (ON INSTRUMENT) ....................................... ca -30 dB
TEMPERATURE RANGE ............................................ -20 to 70 deg C
CONTACTS ..................................................................all hard gold
CONNECTION ............................... XLR, balanced (2m cable length)
0dB = 0dBm=0.775V
WEIGHT.......... < 1 oz
SIZE ............. 1 1/2 inches in diameter
